High Efficiency Ultrasonic H14 Cleanroom HEPA Filters Oven Drying Room

  • 1
  • 2

Brand Name : alphaclean

Model Number : 24*24*12" 595 * 595 * 292

Place of Origin : china

MOQ : 1 pc

Price : negotiation

Payment Terms : L/C, T/T

Supply Ability : 200pcs per week

Delivery Time : 5-8 days

Packaging Details : Polywood packing

Material : fiberglass ,separator

Efficiency : 99.99%

Usage : Final or return filtration for clean rooms

Construction : BOX Filter

Porosity : 0.3um,0.12 um,0.5um

temperature resistant : 300℃

Type : Hepa Filter/ ULPA filter

Application : oven UV drying room

Contact Now

High Efficiency Ultrasonic H14 Cleanroom HEPA Filters Oven Drying Room

High Temperature High Efficiency / Air Filter Ultrasonic Filter For Oven UV Oven Drying Room

300℃ high temperature resistant high efficiency filter H14
Main application: high temperature resistant clean equipment (electronics, biopharmaceutical, medical, chemical, etc.)
Some special process high temperature air supply clean system

Performance description

Frame: SUS304
Filter material: special glass fiber filter paper

Filter separation: aluminum foil
Sealant: Special high-temperature resistant adhesive
Gasket: glass fiber, high temperature resistant polyurethane gasket
Efficiency: H14(EN 1822)99.995% at MPPS(0.3um)

Continuous operating temperature: ≤300 C

Humidity resistance: ≤80% RH

Recommended maximum final resistance: ≤580 Pa

Standard specification

Model

Outside Dimensions

(mm)

Rated Air Flow

(m3/h)

Initial Resistance

(Pa)

Efficiency

(dust-spot)

(%)

Dust Capacity

(g)
GX-2.5J 305×305×150 250 ≤220 ≥99.99 200
GX-4J 320×320×220 400 ≤220 ≥99.99 350
GX-6J 484×484×150 600 ≤220 ≥99.99 400
GX-10J1 484×484×220 1000 ≤220 ≥99.99 600
GX-15J1 726×484×220 1500 ≤220 ≥99.99 900
GX-20J1 968×484×220 2000 ≤220 ≥99.99 1200
GX-10J2 610×610×150 1000 ≤220 ≥99.99 600
GX-15J2 915×610×150 1500 ≤220 ≥99.99 900
GX-20J2 1220×610×150 2000 ≤220 ≥99.99 1200
GX-16J 630×630×220 1600 ≤220 ≥99.99 900
GX-24J 945×630×220 2400 ≤220 ≥99.99 1400
GX-32J 1260×630×220 3200 ≤220 ≥99.99 1800
GX-22J 610×610×292 2200 ≤220 ≥99.99 1200
GX-33J 915×610×292 3300 ≤220 ≥99.99 1800
GX-44J 1220×610×292 4400 ≤220 ≥99.99 2400
